GP6C and GP2569 Airless Painting Equipments are the third generation spraying equipments invented by our factory. Airless Painting Equipments are applicable to the coatings of big components like Tubing,lifting equipment,ships,cars,trailers,bridges,railway vehicles,containers,pipes,tanks aerospace and aviation etc. and coatings of new coating that is hard to be constructed and heavy duty spraying with thick layers, they are also applicable to sprayings like 830,831 coatings for ship use,putties for interior and exterior walls,silver powder coating,regular oil coating,water proof coating,varied coatings etc
Model: GP-6C Airless Painting Equipments
Pressure conversion ratio: 68: 1
No-load displacement(L/min): 14
Inlet pressure(MPa): 0.3-0.6
Air consumption(L/min): 250-2400
Cylinder diameter(mm): Ф250
Dimensions(mm)width×height×high: 550×550×950
Weight(kg): 55
- With extremely large delivery capacity,when it sprays with sprays with a nozzle of the same specification,the motion speed of the hydraulic ram and piston rod becomes slow,which can reduce effectively the deposition and agglomeration of this kind of coating so as to reduce the abrasion and extend the service lifeof the spray equipment;Because the pressure is stable in spraying,the thicknessand quality of the paint film can be regulated and guaranteed in a better way.
- Because many major structures of the coating hydraulic system are all designed according to characteristics of inorganic zinc coating,which makes impossibleof deposition and agglomeration,and majorparts including each high pressure valve port can not be damaged or become worn easily.
Scope：GP-6C Airless Painting Equipments can be spray 830 and 831 paints used in ships,New coating,Heavy film heavy anticorrosion,Polyurethane,Silver paint,Conventional paint,Inside and outside wall putty,Underwater paint,Each kind of coating
Model application：Ships,Steel structure,Automobile,Trailer,Train,Machinery,Grounds around a house,Railroad vehicles,Tunnel,Pipeline,Storage tank,Bridge,Dam,Container,Astronautics aviation
