GP12C-2_Air-assisted paint sprayer
GP12C-2 Air-Assisted Sprayer or Airmix Sprayer was designed to create a new spraying technology which combines the advantages of the conventional and Airless spraying technology.
Air-assisted Sprayer associates middle pressure spraying and an indirect addition of atomization air(at a very low pressure),which leads to outstanding fan control. The outcome of this association is a supercharge of air at the locus of atomization, right after the outflow from the tip, which results in a perfectly controlled and adjustable fan.
Air-assisted spraying provides best solution for the furniture, engineering machinery, coach, renewable energies field. Outstanding finish quality and higher productivity have earned good reputation from customers. We are committed to introduce more new technology for saving your production cost and improving efficiency of application.
Model: GP12C-2 Air-Assisted Sprayer
Pressure exchanging rate 36：1
The most flux: (L/min) 6
Compress air (MPa) 0.3-0.6
To-and-fro times of pump time/min 100
Diameter of cylinder (mm) Ф125
Weight of the whole machine (kg ) 32
The advantages of Air-Assisted Sprayer compared with Airless spraying:
1.Avoid paint particles rebounds, reduce coating consumption by up to 35% and more lower fluid pressure generating less overspray
2.No dry spray occur, lower paint velocity reduces turbulent flow happen
3.Excellent atomization quality and homogeneity of the coating film
4.Lower fluid pressure versus similar technology reduced consumption of nozzles,spray gun and pump
5.No risk of hose burst, reduced the possibility of damage
6.Reduced spray booth maintenance
GP12C-2 Air-assisted sprayers can achieve same spraying performance as Graco Merkur air assisted sprayer (30:1)
